gypsum plasters

Elite MR Elite MR (Moisture Resistance) is a one coat gypsum plaster specifically designed to provide protection in wet areas like bathroom, kitchens, basement, garages, balconies, parking podium etc. It provides extra protection with low absorption of moisture in air or from surface giving excellent results in skirting area application with problems arising out of capillary action and efflorescence. It can be directly used over backgrounds like bricks, blocks and RCC and provides a smooth inert, high quality surface to internal walls and ceilings and a durable base for application of decorative finishes. Application Areas: Saint Gobain Gyproc Elite MR gypsum plaster can be applied on most internal surfaces in wet areas like bathroom, kitchens, basement, garages, balconies, parking podium etc Features & Benefits: Total water absorption <10%* Resists to Moisture from atmosphere and background surface Protects Top Coats (Paints) Protection from Mold and fungal growth Low thermal conductivity (0.25 W/m-K) as compared to Sand Cement Plaster (0.72 W/m-K) ** keeps room cooler in summer and warmer in winter; saving in energy cost Gyproc Elite MR (Moisture Resistant) is a one coat gypsum plaster specifically designed to provide protection in wet areas like bathroom, kitchens, basement, garages, balconies, parking podium etc. It provides extra protection with low absorption of moisture in air or from surface giving excellent results in skirting area application with problems arising out of capillary action and efflorescence. It can be directly used over backgrounds like bricks, blocks, RCC etc. and provides a smooth inert, high quality surface to internal walls and ceilings and a durable base for application of decorative finishes. • Non-combustible (when tested in accordance with BS: 476: part 4:1970), therefore a good form of thermal protection to the building structure. • The water penetration as per DIN 1048 (1960) with Max of 0.3 ml/min. • Excellent Capillary • Water absorption coefficient test method – BS EN 1015-18. • GRIHA and Greenpro Certified Technical & Physical Parameters Dry Bulk Density 880 Kg/m3 (Max) Wet Bulk Density 1.5-1.6 g/cm3 Water To Powder Ratio 1:1.25 Setting Time 15-25 min Water absorption co-efficient (Modified EN 1015-18) < 0.1 kg/(m2.min0.5) Chemical Composition Calcium Sulphate Hemihydrate : CaS04. ½ H2O Identification & Packing Elite MR(Moisture Resistant) is packed in PP bags. The outer layer of the bag is printed with the product image, safety instruction, batch number, date of manufacturing, UOM, correspondence address and application instructions. Available Sizes 25 kg Shelf life time Approx. 3 months from the date of manufacturing when stored in dry conditions. Coverage Applied Thickness 13 mm Coverage* 22 sq-ft/25 kg bag Standard Compliance IS 2547 (Part I)-1976 for Physical and Chemical characteristics Application Storage & Handling Gyproc Elite MR (Moisture Resistant) is supplied in 25Kg bags. The dimensions of the bag ensure that a well-filled appearance is presented when filled and the bags can be stacked on a pallet in a stable and well-stacked array. Bags should be stored dry, as absorption of water shortens the setting time, causes set lumps to form in the bags and may reduce the strength of the set plasterwork. No hooks or any sharp tools should be used to carry bags from one location to another. Background Preparation Surfaces should be completely clean, reasonably dry, protected from the direct exposure from weather and suitable for the chosen specification. In addition, before plastering concrete backgrounds, ensure that any mould oil or other agents present are removed from the surface. No-fines concrete does not require wetting prior to plastering. Plaster should not be applied onto a ‘green’ background or when any free water is visible. Clean water should be applied 5-10 minutes before plaster application to control the suction. In-situ or precast concrete which are exceptionally smooth or having low suction will require pre-treatment with Gyproc Bond-It bonding agent. Mixing Gyproc Elite MR (Moisture Resistant) is pre-mixed with aggregate and only clean water needs to be added to prepare it for use. Mixing should be carried out in a clean tray or bucket. Excessive mechanical mixing shouldte: 24/05/2021 be avoided. Tools and water used in mixing must be clean. Contamination from previous mixes can shorten the setting time and in turn reduce the strength of the plaster when set. Water to plaster ratio (1 part of water: 1.25 part of plaster by weight) should be maintained to have good cohesive workable mix. Prepare plaster mix as much as required depending upon the immediate scope of work. Once the mix has begun to set, additional water is not to be added, as performance properties of plaster will get altered, Gyproc Elite MR (Mo

Elite Machine spray With increasing shortage of Labours in construction industry there is urgent need for mechanized gypsum plastering. Gyproc Elite Machine Spray Plaster is only product that has been developed to adapt the currently available spraying machines in India. Machine Plastering is an efficient way to complete work with less effort and shorter time. Machine Plastering has added benefits of delivering consistent quality, higher productivity, less wastages apart from the most important factor of requirement of 75% less labours ** at site to execute same job. Application Areas: Saint Gobain Gyproc Elite 100 one coat gypsum plaster can be applied on most internal surfaces like Bricks, Blocks & RCC (Concrete) surfaces Elite Machine spray With increasing shortage of Labours in construction industry there is urgent need for mechanized gypsum plastering. Gyproc Elite Machine Spray Plaster is only product that has been developed to adapt the currently available spraying machines in India. Machine Plastering is an efficient way to complete work with less effort and shorter time. Machine Plastering has added benefits of delivering consistent quality, higher productivity, less wastages apart from the most important factor of requirement of 75% less labours ** at site to execute same job. Application Areas: Saint Gobain Gyproc Elite 100 one coat gypsum plaster can be applied on most internal surfaces like Bricks, Blocks & RCC (Concrete) surfaces Elite Machine Spray PDS Elite Machine Spray MSDS Features & Benefits: Higher setting time greater than 90 min * for more productivity and workability Faster and convenient, significantly reducing the time of gypsum plastering Less labours required to execute large projects Low application cost there by having direct saving per Sq Feet** Contains special polymer to help plaster stick to the surface with less wastage Gyproc Xpert is a stucco gypsum plaster made for application on al- most all backgrounds, e.g. brickwork, block work or concrete, as punning agent, creating bull marks and level strips. It consists of Gypsum Hemihy- drate formulated with special additives for enhanced working and set- ting characteristics (10 minutes). It provides perfectly lined and leveled shiny surface without the worry of wastage giving a class leading coverage. Features • Extra whiteness • Doesn’t require water curing • No shrinkage cracks • Non-combustible (when tested in accordance with BS: 476: part 4:1970), therefore a good form of thermal protection to the building structure. • Use of light weight aggregates in the plaster mix help to improve the Thermal resistance. (Thermal Resis- tance R = 0.07m²K/W at 13mm thickness) • GRIHA and Greenpro Certified Technical & Physical Parameters Dry Bulk Density 880 Kg/m3 (Max) Wet Bulk Density 1.4-1.5 g/cm3 Water To Powder Ratio 1:2 Setting Time 8-12 min Chemical Composition Calcium Sulphate Hemihydrate : CaS04. ½ H2O Drying Type Setting Identification & Packing Xpert is packed in HDPE bags. The outer layer of the bag is printed with the product image, safety instruction, batch number, date of manufacturing, UOM, correspondence address and application instructions. Available Sizes 20 kg & 25 kg Shelf life time Approx. 3 months from the date of manufacture.

Gyproc Elite 100 One Coat Gypsum Plaster BP0012 Features • Eliminates two-step process of Sand Cement Plaster and POP punning • Doesn’t require water curing • No shrinkage cracks • Non-combustible (when tested in accordance with BS: 476: part 4:1970), therefore a good form of thermal protection to the building structure. • Use of light weight aggregates in the plaster mix help to improve the Thermal resistance. (Thermal Resistance R = 0.07m²K/W at 13mm thickness) • GRIHA and Greenpro Certified Technical & Physical Parameters Dry Bulk Density 770 Kg/m3 (Max) Wet Bulk Density 1.35-1.5 g/cm3 Water To Powder Ratio 1:1.25 Setting Time 20-25 Minutes Chemical Composition Calcium Sulphate Hemihydrate : CaS04. ½ H2O Drying Type Setting Identification & Packing Elite-100 is packed in PP bags. The outer layer of the bag is printed with the product image, safety instruction, batch number, date of manufacturing, UOM, correspondence address and application instructions. Available Sizes 25 Kg Shelf life time Approx. 3 months from the date of manufacturing when stored in dry conditions Page 2 of 3 Saint Gobain India Pvt Ltd - Gyproc Business reserves the right to revise product specification without notice. The information herein should not be read in isolation as it is meant only as guidance for the user, who should always ensure that they are fully conversant with the products and systems being used and their subsequent installation prior to the commencement of work. *Above parameters are tested under lab conditions. Actual performance depends on site usage, conditions and working. Plasters Last Modification Date - 01/11/2019 Coverage Applied Thickness 13 mm Coverage* 27 sq-ft/25 kg bag Standard Compliance IS 2547 (Part I)-1976 for chemical characteristics IS 2547 (Part II)-1976 for physical characteristics Application Storage & Handling Gyproc Elite-100 is supplied in 25Kg bags. The dimensions of the bag ensure that a well-filled appearance is presented when filled and the bags can be stacked on a pallet in a stable and well-stacked array. Bags should be stored dry, as absorption of water shortens the setting time, causes set lumps to form in the bags and may reduce the strength of the set plasterwork. No hooks or any sharp tools should be used to carry bags from one location to another. Background Preparation Surfaces should be reasonably dry, clean and protected from the weather, and suitable for the chosen specification. In addition, before plastering concrete backgrounds, ensure that any mould oil or other agents present are removed from the surface. No-fines concrete does not require wetting prior to plastering. Plaster should not be applied onto a ‘green’ background or when any free water is visible. Clean water should be applied 5-10 minutes before plaster application to control the suction. In-situ or pre-cast concrete which are exceptionally smooth or having low suction will require pre-treatment with Gyproc Bond-It bonding agent. Mixing Gyproc Elite-100 is pre-mixed with aggregate and only clean water needs to be added to prepare it for use. Mixing should be carried out in a clean tray or bath. Excessive mechanical mixing should be avoided. Tools and water used in mixing must be clean. Contamination from previous mixes can shorten the setting time and in turn reduce the strength of the plaster when set. Water to plaster ratio (1 part of water: 1.25 part of plaster by weight) should be maintained to have good cohesive workable mix. Prepare plaster mix as much as required depending upon the immediate scope of work. Once the mix has begun to set, additional water is not to be added, as performance properties of plaster will get altered, thus affecting workability, cohesiveness, adhesion properties and strength. Application Gyproc Elite-100 should be applied with firm pressure, built out to the required thickness, and ruled to an even surface and left as an undercoat to form a key for finish coat. A thin plaster mix is made and applied as a finish coat to provide smooth surface. It can be applied to an average thickness range of 6-15 mm on walls in one coat and up to 10 mm on ceilings. For thickness above this range, material needs to be applied in two coats . The thickness should not increase to more than 30 mm (average thickness) on walls and 20 mm (average thickness) on ceiling. After complete drying for usually 72 hrs (depends upon thickness and weather conditions) the plain smooth leveled surface is ready for painting. Tiling Tiles up to 20 kg/m2 can be applied directly to the Gyproc Elite100 except where the system includes a bonding agent. Consideration should be given to tiling directly to the background. If plastering to provide a background for tiles avoid polishing the surface. Polished plaster surfaces should be roughened and a suitable primer used. Precaution.
